Suntec Oil Pump E7NC1069

Type: E7NC1069

Application: Heavy oil

Condition: New

Delivery time: Up to 2 weeks

Price: Available on request

The SUNTEC E 1069 oil pump is specially designed for heavy oil applications: it is fitted with a special type shaft seal resisting high temperature and with a preheater location to render cold starting easier.
Applications

– Heavy oil

– One or two-pipe system


General

Mounting: Flange mounting according to EN 225.

Connection threads: Cylindrical according to ISO 228/1.

Inlet and return: G 1/2

Nozzle outlet: G 1/4

Pressure gauge port: G 1/8

Vacuum gauge port: G 1/2

Shaft: ø 11 mm according to European standard EN 225.

Weight: 4 kg


Hydraulic data

Nozzle pressure range: 14 - 30 bars

Oil temperature: 0 - 130 °C in the pump

Pump capacity: 375 l/h max. @ 75cSt

Rated speed: 3600 rpm max.

If you have any questions about this product please email us at info@combustioncontrols.pk
