CJ40-FP-W-P1 (041505)

CJ40-FP-W-P1 (041505) - Capacitive Sensor

Model Number: CJ40-FP-W-P1

Part Nr.: 041505

Switching Element Function: AC NO/NC

Rated Operating Distance: 40 mm

Installation: Non-flush

Output Polarity: AC

Operating Voltage: 20 ... 250 V AC

Product category: Not defined

Brand: Pepperl+Fuchs

Origin: Made in Germany

Condition: New

Stock: 1 piece in surplus (subject to availability)

Price: Available on request

Location on Website: Brands > Pepperl+Fuchs > CJ40-FP-W-P1

40 mm non-flush

2-wire AC

Reverse polarity tolerant

The switching distance can be set over a wide range with the potentiometer

Switching element function: AC NO/NC

Rated operating distance (Sn): 40 mm

Installation: Non-flush

Output polarity: AC

Assured operating distance (Sa): 0...32.4 mm

Operating voltage: 20...250 V AC

Switching frequency: 0...10 Hz

Reverse polarity protection: Reverse polarity tolerant

Operating current: 10...500 mA

Off-state current: 0...2.5 mA typ.

Switching state indication: LED, red

Ambient temperature: -25...+70 °C

Connection type: screw terminals

Sensing face: PBT/POM

Degree of protection: IP65

For more information on technical data, please see data sheet.

If you have any questions about this product please email us at saadwaheed09@gmail.com
