LOA21.171B27 - LOA21.171B27 Landis & Gyr Oil Burner Controller

LOA21.171B27 - Oil Burner Controller

Type: LOA21.171B27

Application: For oil burners

Mains voltage: AC 230 V -15 / +10 %

Ignition Safety Time: 10 seconds max.

Brand: Landis & Gyr

Condition: New

Stock: Subject to availability

Price: Available on request

Note: Plug-in base needs to be ordered separately.

Oil Burner Control

Oil burner control for the supervision, startup and control of single- or 2-stage forced draft oil burners in intermittent operation. Oil throughput up to 30 kg/h.

Use

The LOA... are used for the startup, supervision and control of single- or 2-stage forced draft oil bunrers in intermittent operation. Yellow-burning flames are supervised with photoresistive detectors QRB..., blue-burning flames with blue-flame detectors QRC...

– Forced draft oil burners conforming to EN 267

– Oil atomization burners as monoblocks conforming to EN 230

General unit data

Mains voltage: AC 220 V -15 %...AC 240 V +10 %

Mains frequency: 50...60 Hz ±6 %

External primary fuse (Si): 10 A (fast)

Power consumption: approx. 3 VA

Degree of protection: IP 40, must be ensured through mounting

Mounting position: optional

Weight: approx. 180 g

Temperature range: -20...+60 °C

Humidity: < 95 % r.h.

For more information on technical data, please see data sheet.
