LDU11.523A17 100-110V - LDU11.523A17 Siemens Valve Proving System, Leak test

LDU11.523A17 - Valve Proving System

Type: LDU11.523A17

Mains voltage: AC 100...110 V

Time (t3): 5 s (filling the test space)

Time (t4): 5 s (evacuating the test space)

Brand: Siemens

Condition: New

Availability: 1 pc (subject to availability)

Price: Available on request

Plug-in base: Ordered separately.

Product location: Products > Valve Proving Systems > LDU11.523A17

Valve Proving System for automatic Shutoff Valves

The LDU11... valve proving system is designed for use with shutoff valves in connection with gas burners and gas appliances. In the event of inadmissible leakage, the system prevents the burner from starting up.

LDU11.523A17

Mains voltage: AC 100...110 V

Mains frequency: 50/60 Hz

Time (t3): 5 s (filling the test space)

Time (t4): 5 s (evacuating the test space)

External fuse: Maximum 10 A (slow)

Power consumption: 3.5 VA

Weight: Approx. 1000 g

Weight plug-in base: Approx. 165 g

Mounting orientation: No restrictions

Temperature range (operation): -20...+60 °C

Humidity: < 95 % r.h.

For more information on technical data, please see data sheet.
