61F-GP - Floatless Level Switch

Model: 61F-GP

Application: General-purpose type

No. of pins: 8 pins

No. of electrodes: 3

Supply voltage: 220 VAC

Brand: Omron

Origin: Japan

Condition: Used

Stock: Subject to availability

Plug-in base: Ordered separately

Price: Available on request

Operation

The Conductive Level Controller consists of a plug-in controller connected to a set of stainless steel probes. These are cut to length and inserted vertically into the liquid. A low voltage is applied between these probes and the earth probe (or tank, if it is electrically conductive). The water provides a current between the earth probe and the high-level probe. The output relay in the Controller is energized when the water level reaches the high-level probe and de-enegized when the water level falls below it.

For two-point control a low-level probe is used as well. In this case the relay does not de-energize until the water level falls below the low-level probe. Using the low-level probe allows a wide differential between switching a pump on and off, and can avoid excessive pump operation during tank emptying or filling. If this differential is not required, the low-level probe need not be connected.




























Specifications

Supply voltage: 220 VAC

No. of pins: 8 pins

No. of electrodes: 3

Interelectrode voltage: 8 VAC

Ambient storage temperature: -10 °C to +55 °C

For more information on technical data, please see data sheet.





























If you have any questions about this product please email us at saadwaheed09@gmail.com
